M-10iA/10M

High‑inertia 6‑axis robot with 10 kg payload and 1422 mm reach, delivering fast cycle times, highest wrist moments, and versatile performance.

Request Integration Quote Official Product Link

FANUC M-10iA/10M robot for automation integration

Image source

TECHNICAL OVERVIEW

Integration specifications.

Brand: FANUC
Model: M-10iA/10M
Robot Type: Articulated Robot
Payload: 10 kg
Reach: 1422 mm
Axes: 6
Repeatability: ±0.08 mm
Mounting Method: Contact us for detailed specification
Controller: Contact us for detailed specification
Protection Rating: Contact us for detailed specification
Application: Handling, Machine Tending

Additional Specification

Axes: 6
Max Payload: 10 kg
Repeatability: ±0.08 mm
Reach: 1422 mm
Mechanical Weight: 130 kg
J1 Motion Range: 360°
J2 Motion Range: 250°
J3 Motion Range: 445°
J4 Motion Range: 400°
J5 Motion Range: 280°
J6 Motion Range: 720°
J1 Speed: 225°/s
J2 Speed: 205°/s
J3 Speed: 225°/s
J4 Speed: 420°/s
J5 Speed: 420°/s
J6 Speed: 700°/s

BEST FOR

Recommended integration applications.

Handling, Machine Tending

Selection note

Final robot selection depends on process, payload, reach, cycle time, environment, tooling and safety requirements. Product brands shown are selectable integration platforms.
