R-2000-125F-31E

Versatile floor-mounted robot with 125 kg payload and 3100 mm reach, delivering precise performance with the FANUC R-50iA controller.

Request Integration Quote Official Product Link

FANUC R-2000-125F-31E robot for automation integration

Image source

TECHNICAL OVERVIEW

Integration specifications.

Brand: FANUC
Model: R-2000-125F-31E
Robot Type: Articulated Robot
Payload: 125 kg
Reach: 3100 mm
Axes: 6
Repeatability: ±0.05 mm
Mounting Method: Contact us for detailed specification
Controller: R-50iA
Protection Rating: Contact us for detailed specification
Application: Handling, Machine Tending

Additional Specification

Controller Series: R-50iA
Axes: 6
Max Payload: 125 kg
Mounting Method: Floor
Repeatability: ±0.05 mm
Reach: 3100 mm
Mechanical Weight: 1125 kg
Average Power Consumption: 2.5 kW
J1 Motion Range: 370°
J2 Motion Range: 136°
J3 Motion Range: 346°
J4 Motion Range: 720°
J5 Motion Range: 250°
J6 Motion Range: 720°
J1 Speed: 130°/s
J2 Speed: 120°/s
J3 Speed: 140°/s
J4 Speed: 220°/s
J5 Speed: 220°/s
J6 Speed: 300°/s
J4 Moment / Inertia: 760/100
J5 Moment / Inertia: 760/100
J6 Moment / Inertia: 415/75
Body Standard / Optional: STANDARD
Wrist & J3 Arm: STANDARD

BEST FOR

Recommended integration applications.

Handling, Machine Tending

Selection note

Final robot selection depends on process, payload, reach, cycle time, environment, tooling and safety requirements. Product brands shown are selectable integration platforms.
