R-2000-300F-27E

Ultra heavy-duty floor robot with 300 kg payload and 2655 mm reach, powered by the R-50iA controller for extreme industrial tasks that require a heavy…

Request Integration Quote Official Product Link

FANUC R-2000-300F-27E robot for automation integration

Image source

TECHNICAL OVERVIEW

Integration specifications.

Brand: FANUC
Model: R-2000-300F-27E
Robot Type: Articulated Robot
Payload: 300 kg
Reach: 2655 mm
Axes: 6
Repeatability: ±0.05 mm
Mounting Method: Contact us for detailed specification
Controller: R-50iA
Protection Rating: Contact us for detailed specification
Application: Handling, Machine Tending

Additional Specification

Controller Series: R-50iA
Axes: 6
Max Payload: 300 kg
Mounting Method: Floor
Repeatability: ±0.05 mm
Reach: 2655 mm
Mechanical Weight: 1365 kg
Average Power Consumption: 3 kW
J1 Motion Range: 370°
J2 Motion Range: 136°
J3 Motion Range: 362°
J4 Motion Range: 720°
J5 Motion Range: 250°
J6 Motion Range: 720°
J1 Speed: 110°/s
J2 Speed: 95°/s
J3 Speed: 90°/s
J4 Speed: 130°/s
J5 Speed: 130°/s
J6 Speed: 210°/s
J4 Moment / Inertia: 1770/320
J5 Moment / Inertia: 1770/320
J6 Moment / Inertia: 1020/230
Body Standard / Optional: STANDARD
Wrist & J3 Arm: STANDARD

BEST FOR

Recommended integration applications.

Handling, Machine Tending

Selection note

Final robot selection depends on process, payload, reach, cycle time, environment, tooling and safety requirements. Product brands shown are selectable integration platforms.
